C9300-48T-E Catalyst 9300 48-port data only Network Essentials
C9300-48T-E Catalyst 9300 48-port data only Network Essentials
C9300-48T-E Catalyst 9300 48-port data only Network Essentials
C9300-48T-E Catalyst 9300 48-port data only Network Essentials
C9300-48T-E Catalyst 9300 48-port data only Network Essentials
C9300-48T-E Catalyst 9300 48-port data only Network Essentials
C9300-48T-E Catalyst 9300 48-port data only Network Essentials
C9300-48T-E Catalyst 9300 48-port data only Network Essentials
Specifications
Brand Name :
Cisco
Model Number :
C9300-48T-E
Certification :
CE
Place of Origin :
USA
Model :
C9300-48T-E
Switching capacity :
256 Gbps on 48-port Gigabit Ethernet model
Stacking bandwidth :
480 Gbps
DRAM :
8 GB
Flash :
16 GB
Forwarding rate :
154.76 Mpps
Dimensions :
1.73 x 17.5 x 17.5 Inches
Weight :
16.33 Pounds
Condition :
Brand New Sealed
Warranty :
1 year
Payment :
T/T, Western Union, Paypal
Shipment :
DHL, Fedex, UPS
Description

C9300-48T-E Overview

The Cisco® Catalyst® 9300 Series Switches are Cisco’s lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. C9300-48T-E is 48-port data only, Network Essentials Switch of 9300 series. Catalyst 9300 Series are the next generation of the industry’s most widely deployed switching platform. At 480 Gbps, they are the industry’s highest-density stacking bandwidth solution with the most flexible uplink architecture. The Catalyst 9300 Series is the first optimized platform for high-density 802.11ac Wave2. It sets new maximums for network scale. These switches are also ready for the future, with an x86 CPU architecture and more memory, enabling them to host containers and run third-party applications and scripts natively within the switch.

C9300-48T-E Catalyst 9300 48-port data only Network EssentialsC9300-48T-E Catalyst 9300 48-port data only Network Essentials

Compare to Similar Items

Product Code C9300-48T-E C9300-24P-A
Product Description Catalyst 9300 48-port data only, Network Essentials Catalyst 9300 24-port PoE+, Network Advantage
Total 10/100/1000 or Multigigabit copper ports 48 24 POE+
Default AC power supply 350WAC 715W AC
Available PoE power -- 445W
Dimensions (H x W x D) 1.73 x 17.5 x 17.5 Inches 1.73 x 17.5 x 17.5 Inches
Weight 16.33 Pounds 16.33 Pounds

C9300-48T-E Specification

C9300-48T-E Specification
Part Number C9300-48T-E
Product Description Catalyst 9300 48-port data only, Network Essentials
Total 10/100/1000 or Multigigabit copper ports 48
Default AC power supply 350WAC
Available PoE power --
Cisco StackWise-480 Yes
Cisco StackPower Yes
Default power supply PWR-C1-350WAC-P/2
Switching capacity 256 Gbps on 48-port Gigabit Ethernet model
Stacking bandwidth 480 Gbps
Total number of MAC addresses 32,000
Total number of IPv4 routes (ARP plus learned routes) 32,000 (24,000 direct routes and 8000 indirect routes)
IPv4 routing entries 32,000
IPv6 routing entries 16,000
Multicast routing scale 8000
QoS scale entries 5120
ACL scale entries 5120
Packet buffer per SKU 16 MB buffer for 24- or 48-port Gigabit Ethernet models
FNF entries 64,000 flow on 24- and 48-port Gigabit Ethernet models
DRAM 8 GB
Flash 16 GB
VLAN IDs 4000
Total Switched Virtual Interfaces (SVIs) 2000
Jumbo frames 9198 bytes
Total routed ports per 9300 Series stack 208
Wireless bandwidth per switch Up to 96 Gbps on 48-port Gigabit Ethernet model
Forwarding rate 154.76 Mpps
Dimensions (H x W x D) 1.73 x 17.5 x 17.5 Inches
Weight 16.33 Pounds
Mean time between failures (hours) 299,000
Safety certifications

● UL 60950-1

● CAN/CSA-C222.2 No. 60950-1

● EN 60950-1

● IEC 60950-1

● AS/NZS 60950.1

● IEEE 802.3
Electromagnetic emissions certifications

● 47 CFR Part 15

● CISPR22 Class A

● EN 300 386 V1.6.1

● EN 55022 Class A

● EN 55032 Class A

● CISPR 32 Class A

● EN61000-3-2

● EN61000-3-3

● ICES-003 Class A

● TCVN 7189 Class A

● V-3 Class A

● CISPR24

● EN 300 386

● EN55024

● TCVN 7317
Environmental Reduction of Hazardous Substances (ROHS) 5

C9300-48T-E Catalyst 9300 48-port data only Network Essentials
