Specifications
Brand Name :
Suzhou Desisen (DSS) Electronics
Model Number :
598
Certification :
ISO 9001, CE
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
100 sets
Delivery Time :
10-20 days
Packaging Details :
wooden case
advanced :
t adopts the most advanced DSP and FPGA digital electronic technology, far-field eddy current technology and microprocessor technology
Good performance :
With multi-frequency, eddy current detection instrument advanced performance, especially with high sampling rate and ultra-low noise and high signal-to-noise ratio
Wide detection range :
Used to detect a variety of metal parts testing equipment including signal power source, signal measurement, signal recording and processing, made into a tube can pass the form
Built-in lithium battery :
A full charge lasts 6-8 hours
Description

Product Description:

598 portable eddy current detector to electromagnetic base placed on the probe on the material to be detected, the probe has an excitation coil, there is a (or two) detection coil, detection has the following advantages: the surface of the material to be detected do not have to clean; probe and material surface does not contact, the gap between the probe outer diameter and the material inner diameter of the gap between the changes on the detection results of a very small effect. The detection sensitivity of the inner and outer surfaces of the material is the same; the detection of uniform thinning, gradual thinning and partial wear thinning have extremely high detection sensitivity; the detection speed of the probe is uniform or not has no effect on the detection results; the gas and liquid medium within the material has no effect on the detection results; the detection equipment is small in size and light in weight, which is convenient for flexible on-site application.

Features:

The 598 Portable Eddy Current Flaw Detector is a new-generation eddy current non-destructive testing equipment. It adopts the most advanced DSP and FPGA digital electronic technologies, far-field eddy current technology, and microprocessor technology, which can effectively detect defects in metal components in real time. During detection, it is not affected by probe lift-off, skin effect, uneven electrical conductivity, or magnetic permeability.


The 598 Portable Eddy Current Flaw Detector is a complete far-field eddy current testing system, featuring advanced performance of multi-frequency eddy current testing instruments. In particular, its high sampling rate, ultra-low noise, and high signal-to-noise ratio make it a new-type eddy current testing equipment in the Asia-Pacific region, characterized by high performance, multi-functionality, and intelligence.

Technical Parameters:

Name Portable Eddy Current Flaw Detector FET-9HS
Frequency range 1 Hz ~ 20 MHz (far field frequency 1Hz ~ 20KHz);
Gain 0 ~ 90dB, step 0.5dB
Phase rotation 0 ~ 359° step 1 °
Gain ratio (Y/X) 0.1 ~ 10
Gain/Phase Measurement manual/automatic
Display Mode Dot/Line/Fade
High-pass Filter Off, 0 ~2000Hz
Low Pass Filter Off, 10~2000kHz
Display Semi-reflective LCD with backlight, suitable for long term observation in darkness or direct sunlight
scanning erase, refresh and retain three scanning modes
filter digital and analogue filter
Operating Temperature -15~55℃
Storage Temperature -20~60℃
Relative Humidity not more than 85%
Operating Voltage AC220±10V

With probe automatic zero system

fast mode digital / proposed electronic balance

automatic (manual) eddy current signal amplitude, phase measurement, eddy current signal slow (adjustable) expansion of playback

time base scanning and impedance plane map on the same screen

with the configuration of the analysis function

with a unique non-equal amplitude phase / amplitude alarm domain

the hardware alarm output port

can be stored in a variety of massive testing procedures and test data

automatic Amplitude, phase / defect depth curve display

right-angle coordinate system and polar coordinate system background selection

comes with lithium batteries (fully charged can be used for 6-8 hours)

the number of points of digital filtering: 1 ~ 100

the hardware alarm output

the alarm output signal

Support and Services:

Technical Support and Service for Portable Eddy Current Flaw Detector

We provide technical support and service to ensure our customers are satisfied with their Portable Eddy Current Flaw Detector. We offer both on-site and online support for all of our products.

On-site Support

Our on-site support team is available to help with any installation, troubleshooting, or maintenance related issues you may have with your Portable Eddy Current Flaw Detector. Our technicians can come to your location and help with any questions or problems you may have.

Online Support

Our online support team is available 24/7 to help with any questions or issues you may have with your Portable Eddy Current Flaw Detector. We have a live chat feature on our website, as well as an online ticket system for more in-depth issues. Our team is always available to help.

FAQ:

Q1: What is the brand name of this product?

A1: The brand name of this product is Desisen.

Q2: What is the model number of this product?

A2: The model number of this product is 598.

Q3: Where is this product made?

A3: This product is made in China.

Q4: Does this product have any certification?

A4: Yes, this product has ISO9001 certification.

Q5: What's the minimum order quantity?

A5: The minimum order quantity is 1.
