Specifications
Brand Name :
Pdfy/OEM
Place of Origin :
China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
T/T,PayPal
Model NO. :
PF-MO012A
Application :
Anti Drone System
Usage :
Anti Drone System
Product Name :
RF GaN Power Amplifier Module
Output Power :
10W
Gain :
40 dBm
Voltage :
24-32V
Type :
Drone Uav Protect Module
Product Weight :
136g
Intra-Band Fluctuations :
≤2.5 (Peak-to-Peak Value)
in-Band Group Delay :
≤1us
Input Voltage Standing Wave Ratio :
≤1.35
Transport Package :
Carton
Specification :
29.7*131*15.5mm
Trademark :
PADIFLY/OEM
Origin :
Guangdong, China
Description

433MHz 10W GaN RF Module Anti Drone Signal Jammer

Product Parameters
GaN transistors are more efficient.
The efficiency minus the driver (heating power consumption) is about 55-65%.
In fact, the working efficiency over 2.4G is 52%, and the working efficiency below 2.4G is 55%.
However, the working efficiency of LDMOS modules is only 45%-55%, so GaN modules consume less power and generate heat slowly.
--GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module.

--We provide broadband and band specific, high power RF and microwave amplifier solutions to OEM
Brand Name
PDFY
Working frequency
433MHz
Saturated output power
40±1dBm
Gain
42±2dB
In-band fluctuation
≤2.0dB

Out-of-band spurious
9kHz~1GHz:≤-36dBm/30kHz
1GHz~12.75GHz:≤-30dBm/30KHz
Input VSWR
≤1.5
Gain temperature stability
≤±1.5dB
Working voltage
DC+28V
Power supply monitoring interface
Power supply and power amplifier enabling: through the heart capacitor
Output RF port
SMA
Dimensions
29.7*131*15.5mm(excluding SMA)
Working temperature
-20~+55ºC
Efficient 433MHz 10W GaN RF Amplifier Module Anti Drone Signal Jammer ModuleEfficient 433MHz 10W GaN RF Amplifier Module Anti Drone Signal Jammer Module
Efficient 433MHz 10W GaN RF Amplifier Module Anti Drone Signal Jammer ModuleEfficient 433MHz 10W GaN RF Amplifier Module Anti Drone Signal Jammer Module
Efficient 433MHz 10W GaN RF Amplifier Module Anti Drone Signal Jammer ModuleEfficient 433MHz 10W GaN RF Amplifier Module Anti Drone Signal Jammer Module
Packaging & Shipping
Selling Units:
Single item
Single package size:
20X20X10 cm
Single gross weight:
0.3kg
Package Type:
Each piece is individually packed into a bag and then packed into a carton.
